High Pressure Valves, Fittings and Tubing

30,000,  40,000 and 60,000 psi service.

High Pressure Equipment Company have developed a line of High Pressure products to assure safe and easy plumbing for 30,000,  40,000 and 60,000 psi.  These needle valves, fittings, line filters, check valves, safety heads, rupture discs, anti-vibration gland assemblies, tubing and nipples are engineered to the highest standards of repeatable quality.  The reliable performance of these products has made HiP one of the world's leading suppliers of elevated pressure components.

High Pressure components use a coned-and-threaded connection which accommodates the high temperatures and pressures common in these applications.  High Pressure valves are available in various tubing sizes and with body designs to satisfy widely varied requirements.  A line of fitting is available to facilitate adapting to Taper Seals, Medium Pressure, or other High Pressure threaded pipe systems.

General

  • Valve bodies through 100,000 psi are high tensile Type 316 stainless steel, 150,000 psi valve bodies are 17-4 PH stainless steel.
  • Stem assemblies have non-rotating tips to prevent galling with valve seats.
  • Packing is located below the stem threads to prevent contact with media (liquid or gas).
  • Packing glands are equipped with locking devices or lock nuts.
  • Six valve patterns (see chart on page 1.3).
  • Tubing connections are: 1/16', 1/8', 1/4', 3/8', 9/16', 3/4', and 1'. Pipe connections include: 1/8', 1/4', 3/8', 1/2', 3/4', and 1' NPT.
  • Remote control air operators are available for most valves.
High Pressure Connections
Nipples
Anti-Vibration Gland Assemblies
Anti-Vibration Gland Assemblies
Safety Heads
Rupture Discs
Excess Surge Check Valves
Soft Seat Check Valves
Ball Check Valves
Line Filters
Caps
Bulkhead Couplings
Union Couplings (Slip Type)
Glands, Sleeves, Plugs, Elbows, Tees, Crosses
60,000 psi High Pressure Valves
40,000 psi High Pressure Valves
30,000 psi High Pressure Valves
